• Air conditioning, dual-zone, manual, individual climate settings for driver & right front passenger
• Assist handle, front passenger, dash-mounted
• Cigarette lighter, on instrument panel
• Coat hook, driver side
• Cupholders, front
• Door trim, side reflectors
• Floor covering, Graphite-colored rubberized vinyl
• Headliner, Shale-colored cloth, w/matching retainer moldings
• Lighting, dome lamp, reading, courtesy, illuminated entry feature, backlit instrument panel switches & door handle-activated illuminated entry
• Mirror, inside rearview, manual day/night
• Power outlets, auxiliary, covered, 2 dash-mounted, 12-volt
• Seats, front cloth 40/20/40 split-bench, 3-passenger w/outboard head restraints & manual recliners
• Sound system feature, 4-speakers
• Sound system, ETR AM/FM stereo-inc: seek-&-scan, & digital clock
• Steering wheel, steel sleeve-inc: theft-deterrent locking feature
• Theft-deterrent system, PASSLock II
• Visors, padded, Shale-colored, driver & passenger side w/cloth trim, extenders, pocket on driver side & vanity mirror on passenger side
• Warning tones, headlamp on, key-in-ignition, driver safety belt unfasten, turn signal on

• 34 gallon fuel tank
• Alternator, 105 amps
• Battery, heavy-duty, 600 cold-cranking amps-inc: rundown protection & retained accessory power
• Brakes, 4-wheel antilock, 4-wheel disc
• Exhaust, aluminized stainless-steel muffler & tailpipe
• Four wheel drive
• Frame, ladder type
• GVWR, 6400 lbs. (2903 kg)
• Pickup bed, Wideside, all-welded steel w/double wall construction & corrosion protection
• Recovery hooks, 2 front, frame-mounted
• Steering, power
• Suspension Package, Solid Smooth Ride
• Suspension, front, independent torsion bar
• Suspension, rear, semi-elliptic 2-stage multi-leaf springs
• Tire carrier, outside spare, winch-type mounted under frame at rear
• Tires, P245/75R16, all-season, blackwall
• Tools, mechanical jack & wheel wrench, gloves, courtesy mat, spare tire assist hook, floor-mounted in back of cab
• Transfer case, floor-mounted shifter
• Wheels, 4 - 16" x 7" (40.6 cm x 17.8 cm) 6-lug steel, painted-inc: painted center caps & steel spare

• Air bags, frontal, driver & right front passenger-inc: Passenger Sensing System
• Brakes, 4-wheel antilock, 4-wheel disc
• Daytime running lamps-inc: automatic exterior lamp control

ENGINE, VORTEC 4300 V6 MFI

• 200 HP [149.2 kW] @ 4600 rpm
• 260 lb.-ft. [351.0 N-m] @ 2800 rpm

• Multi-Zone A/C
• Cloth Seats
• Adjustable Steering Wheel
• Power Outlet

• Mileage
• EPA Fuel Economy Est - City (MPG): 14
• EPA Fuel Economy Est - Hwy (MPG): 18
• Electrical
• Cold Cranking Amps @ 0° F (Primary): 600
• Maximum Alternator Capacity (amps): 105
• Cooling System
• Total Cooling System Capacity (qts): 11.72
• Total Cooling System Capacity (qts): 13.6
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 3600
• Gross Axle Wt Rating - Rear (lbs): 3750
• Curb Weight - Front (lbs): 2632
• Curb Weight - Rear (lbs): 1765
• Gross Vehicle Weight Rating Cap (lbs): 6400
• Gross Combined Wt Rating (lbs): 12000
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 500
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 7000
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 700
• Fifth Wheel Hitch - Max Trailer Wt. (lbs): 7000
• Fifth Wheel Hitch - Max Tongue Wt. (lbs): 1050
• Suspension
• Suspension Type - Front: Torsion Bar
• Suspension Type - Rear: 2-Stage Multi-Leaf
• Spring Capacity - Front (lbs): 3925
• Spring Capacity - Rear (lbs): 3750
• Axle Type - Front: Independent
• Axle Type - Rear: Semi-Floating
• Axle Capacity - Front (lbs): 3925
• Axle Capacity - Rear (lbs): 3750
• Axle Ratio (:1) - Front: 3.73
• Axle Ratio (:1) - Rear: 3.73
• Shock Absorber Diameter - Front (mm): 35
• Shock Absorber Diameter - Rear (mm): 35
• Stabilizer Bar Diameter - Front (in): 1.12
• Stabilizer Bar Diameter - Rear (in): - TBD -
• Brakes
• Brake Type: Pwr
• Brake ABS System: Four-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 12.0 x 1.10
• Rear Brake Rotor Diam x Thickness (in): 12.8 x 0.78
• Tires
• Front Tire Order Code: QNK
• Rear Tire Order Code: QNK
• Spare Tire Order Code: QNK
• Front Tire Size: P245/75R16
• Rear Tire Size: P245/75R16
• Spare Tire Size: P245/75R16
• Front Tire Capacity (lbs): 2064
• Rear Tire Capacity (lbs): 2064
• Spare Tire Capacity (lbs): 2064
• Revolutions/Mile @ 45 mph - Front: - TBD -
• Revolutions/Mile @ 45 mph - Rear: - TBD -
• Revolutions/Mile @ 45 mph - Spare: - TBD -
• Wheels
• Front Wheel Size (in): 16 x 7
• Rear Wheel Size (in): 16 x 7
• Spare Wheel Size (in): 16 x 7
• Front Wheel Material: Steel
• Rear Wheel Material: Steel
• Spare Wheel Material: Steel
• Steering
• Steering Type: Pwr
• Steering Ratio (:1), On Center: 14.2
• Steering Ratio (:1), At Lock: - TBD -
• Turning Diameter - Curb to Curb (ft): 42.9
• Turning Diameter - Wall to Wall (ft): - TBD -
• Frame
• Frame Type: Ladder
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 34
• Fuel Tank Location: LH
• Exterior Dimensions
• Wheelbase (in): 133.0
• Length, Overall w/o rear bumper (in): 222.1
• Width, Max w/o mirrors (in): 78.5
• Height, Overall (in): 73.7
• Overhang, Front (in): 36.9
• Overhang, Rear w/o bumper (in): 52.2
• Front Bumper to Back of Cab (in): 114.0
• Cab to Axle (in): 55.9
• Cab to End of Frame (in): - TBD -
• Ground to Top of Load Floor (in): 33.0
• Ground to Top of Frame (in): - TBD -
• Frame Width, Rear (in): - TBD -
• Ground Clearance, Front (in): 10.6
• Ground Clearance, Rear (in): 13.6
• Cargo Area Dimensions
• Cargo Box Length @ Floor (in): 97.6
• Cargo Box Width @ Top, Rear (in): 64.8
• Cargo Box Width @ Floor (in): 64.8
• Cargo Box Width @ Wheelhousings (in): 50.0
• Cargo Box (Area) Height (in): 19.5
• Tailgate Width (in): 64.8
• Cargo Volume (ft³): 70.7
• Interior Dimensions
• Passenger Capacity: 3
• Front Head Room (in): 41.0
• Front Leg Room (in): 41.3
• Front Shoulder Room (in): 61.4
• Front Hip Room (in): 63.9
• Summary
• Vehicle Name: GMC Sierra 1500
• Body Style: Reg Cab 8' Wideside
• Body Code: E63
